SRP200F
Battery Strap PTC, PolySwitch SRP, 30 VDC, 2 A, 4.4 A, 4 s, 100 A
2 000 Nu kan du reservera lagervaror
| Antal | |
|---|---|
| 1+ | 8,040 kr |
| 50+ | 5,760 kr |
| 100+ | 5,510 kr |
| 250+ | 5,260 kr |
| 500+ | 4,850 kr |
| 1000+ | 4,490 kr |
Produktinformation
Produktöversikt
The SRP200F is a 2A PolySwitch Resettable Device with quarter-hard nickel leads and polyester tape. Raychem Circuit Protection, pioneer of polymeric PTC resettable device has developed several material platforms specifically tailored to help protect battery applications. Each of these material platforms offers different performance characteristics, allowing the engineer greater design flexibility. This SRP battery protector is compatible with high-volume electronics assembly and assists in meeting regulatory requirements. This resettable device increases battery operating time.
- Fast time-to-trip
- Low resistance devices increase battery operating time
Tillämpningar
Power Management, Portable Devices, Communications & Networking, Consumer Electronics
Varningar
Intended for protection against occasional over-current or over-temperature fault conditions and should not be used when repeated fault conditions or prolonged trip events are anticipated.
Tekniska specifikationer
PolySwitch SRP
30VDC
4.4A
100A
85°C
Strap
2A
4s
-40°C
-
Teknisk dokumentation (2)
Alternativ till SRP200F
1 produkt hittades
Tillhörande produkter
1 produkt hittades
Lagstiftning och miljö
Det land där den sista betydelsefulla tillverkningsprocessen utfördesUrsprungsland:China
Det land där den sista betydelsefulla tillverkningsprocessen utfördes
RoHS
RoHS
Certifikat för produktefterlevnad
