Skriv ut sida
Produktinformation
TillverkareHARWIN
Tillverkarens art.nr.M80-2840045
Orderkod1667044
ProduktsortimentDatamate
Tekniskt datablad
Product RangeDatamate
Contact GenderSocket
Contact Termination TypeCrimp
Wire Size AWG Max26AWG
Contact PlatingGold Plated Contacts
For Use WithM80-454, M80-455, M80-456, M80-457, M80-458 or M80-459 Moulds
Wire Size AWG Min28AWG
Contact MaterialBeryllium Copper
Alternativ till M80-2840045
3 produkter hittades
Produktöversikt
The Datamate series high performance/high reliability Connector range is approved to meet the exacting requirements of British Standard 9525-F0033, this conformity is made possible by Harwin's high reliability 4 finger beryllium copper contact technology. The contact features a 4 finger beryllium copper clip to ensure integrity of connection under the most severe conditions. The Datamate range is ideal for applications where safety is key, the application is subject to high loads of vibration and shock or operates in harsh environments.
- J-Tek and L-Tek fixing variants offer additional security
- Mates with known industry equivalents
- Ideal for COTS applications
Tillämpningar
Industrial, Aerospace, Defence, Military
Tekniska specifikationer
Product Range
Datamate
Contact Termination Type
Crimp
Contact Plating
Gold Plated Contacts
Wire Size AWG Min
28AWG
Contact Gender
Socket
Wire Size AWG Max
26AWG
For Use With
M80-454, M80-455, M80-456, M80-457, M80-458 or M80-459 Moulds
Contact Material
Beryllium Copper
Teknisk dokumentation (5)
Lagstiftning och miljö
Ursprungsland:
Det land där den sista betydelsefulla tillverkningsprocessen utfördesUrsprungsland:Great Britain
Det land där den sista betydelsefulla tillverkningsprocessen utfördes
Det land där den sista betydelsefulla tillverkningsprocessen utfördesUrsprungsland:Great Britain
Det land där den sista betydelsefulla tillverkningsprocessen utfördes
Tariffnr:85366990
US ECCN:EAR99
EU ECCN:NLR
RoHS-kompatibelt:Ja
RoHS
RoHS-kompatibel för ftalater:Ja
RoHS
Hämta certifikat för produktefterlevnad
Certifikat för produktefterlevnad
Vikt (kg):.000071
