PYBE30-Q48-S24H

PYBE30-Q48-S24H is a PYBE30 series high efficiency isolated DC/DC converter with heatsink. It is housed in a compact DIN rail package designed for easy installation in control cabinets. Supporting a 4:1 input range, single regulated output, and an operating temperature range of -40 to +85°C, this is encapsulated, DIN rail DC/DC converter provide a rugged solution for use in harsh environments including factory automation and industrial control applications. It includes over voltage, over current, short circuit protection. Safety approvals are certified to 62368-1: EN, BS EN, certified to 60950: UL.

• 48VDC typical input voltage, 24VDC output voltage
• 0 to 1250mA output current range, 30W maximum output power
• 87% typical efficiency (measured at nominal input voltage, full load)
• Industry standard pin-out, 1500VDC isolation
• 300KHz typical switching frequency (PWM mode)
• Aluminium alloy case material
• 2 years limited warranty
• Dimension is 51.40 x 26.20 x 16.50mm
